Slope gets all the attention in ramp planning, and then the ramp gets built and someone discovers they cannot open the door at the top. Width and landings are the requirements that decide whether a ramp is usable once you are actually on it, and they consume far more of the yard than most people expect.
This guide covers the clear width, landing sizes, edge protection, and door clearance figures the ADA standard specifies, then shows how they add up on a real footprint so you can check whether the ramp you have in mind will fit before anything is ordered.
This article contains affiliate links. If you buy through them, we may earn a commission at no extra cost to you. Learn more.
Quick Answer
How wide does a wheelchair ramp need to be, and how big are the landings?
- The ADA standard specifies a clear width of 36 inches minimum, measured between the handrails rather than to the outside of the structure.
- Landings at the top and bottom of each run must be 60 inches long minimum and at least as wide as the ramp run leading into them.
- Where the ramp changes direction, the landing must be 60 by 60 inches minimum.
- Landings must be essentially level, with a slope no steeper than 1:48 in any direction.
Edge protection is required along ramp runs and landings to stop a wheel dropping off the side.
Width and Landing Requirements at a Glance
These figures come from section 405 of the 2010 ADA Standards for Accessible Design, with the door clearance rules cross-referenced from section 404. They apply to the facilities the ADA covers rather than to private homes, though the space arithmetic is the same wherever you build.
| Requirement | What the ADA standard specifies |
|---|---|
| Clear width of run | 36 inches minimum, measured between handrails |
| Landing length | 60 inches minimum at the top and bottom of every run |
| Landing width | At least as wide as the widest ramp run leading to it |
| Turning landing | 60 by 60 inches minimum where the ramp changes direction |
| Landing slope | No steeper than 1:48 in any direction, with no changes in level |
| Maximum rise per run | 30 inches, after which a landing is required |
| Edge protection | Required on each side of ramp runs and landings |
| Curb or barrier option | Must stop a 4 inch sphere passing where it is within 4 inches of the surface |
| Doorway clearance | Door maneuvering clearances may overlap the required landing area |
Clear Width Is Measured Between the Handrails
The ADA standard specifies a clear width of 36 inches minimum for a ramp run, and the word clear is doing real work. The measurement is taken between the handrails, so the structure itself has to be wider than 36 inches to deliver it once rails, posts, and curbs are installed.
This is the single most common ordering mistake with modular ramps. A ramp sold as 36 inches wide may measure 36 inches across the deck, leaving less than that once the rails are on. Check what the manufacturer means by width before comparing two products.
Why 36 Inches
Thirty-six inches accommodates a wheelchair plus the space the user’s hands need on the pushrims, and it leaves room to correct a line without a wheel finding the edge. Anything narrower forces a straight line, and a straight line is difficult to hold on a slope with a cross wind or an uneven surface.
Landings Do Three Different Jobs
The ADA standard requires a landing at the top and bottom of every ramp run, 60 inches long minimum and at least as wide as the run leading into it. The 60 inches is a resting length: it gives a person room to stop with the whole chair on a level surface rather than balanced half on the slope.
Where a ramp changes direction, the landing grows to 60 by 60 inches minimum, because a turn needs a square rather than a rectangle. And the standard requires landings to be effectively level, with a slope no steeper than 1:48 in any direction and no changes in level, so a chair left standing on one does not creep.
The Bottom Landing Is Not Optional Either
A ramp that runs straight onto a sloping driveway has no bottom landing, and the transition from a 1:12 slope onto a driveway pitch is where front casters catch. If the ground at the base is not level, the landing has to be built rather than assumed.
Doors, the Thing That Ruins Otherwise Good Plans
A ramp usually ends at a door, and doors have their own space requirements. The ADA standard sets a clear opening width of 32 inches minimum for doorways and specifies maneuvering clearances on the approach side, including additional space beside the latch so a seated person can reach the handle and pull the door past themselves.
The standard does allow those maneuvering clearances to overlap the required landing area, which helps, but it does not remove the problem of an outward swinging door. If the door opens onto the landing, the landing has to be large enough that the swing does not push a chair backward toward the ramp. Planning the door before the ramp is the order that avoids rework.
Edge Protection
Edge protection keeps a caster from rolling off the side of the ramp, and the ADA standard requires it on each side of ramp runs and landings. It offers more than one way to provide it: extending the walking surface at least 12 inches beyond the inside face of the handrail, or fitting a curb or barrier that stops a 4 inch sphere from passing where any part of the sphere is within 4 inches of the surface.
On a modular aluminum ramp the curb is usually built into the deck section. On a wood ramp it is a rail at deck level, which is a separate piece from the handrail above. Our guide to ramp railings covers how the two work together.
Adding It Up on a Real Footprint
Take a porch 24 inches above the walkway. At the 1:12 slope the ADA standard specifies, the ramp surface is 24 feet. Add a 5 foot landing at the top and a 5 foot landing at the bottom and the straight run needs 34 feet of yard, in a strip at least 4 feet wide once rails are accounted for.
Fold that into two 12 foot runs with a 60 by 60 inch turning landing between them and the same ramp fits into roughly 17 feet by 9 feet. That is the calculation worth doing on paper before ordering. Our ramp length walkthrough covers the slope arithmetic, and the full ADA ramp requirements put all the pieces together.
When the Yard Simply Cannot Take It
Sometimes the numbers do not fit, and the honest answer is a different approach rather than a steeper ramp. That might mean using a different entrance with a lower rise, regrading the approach, or using a portable ramp for occasional visits rather than building a permanent structure. If you are unsure what fits your situation, ask your doctor or an occupational therapist, who can look at the entrance and the person together.
Frequently Asked Questions
How wide does an ADA ramp have to be? The ADA standard specifies 36 inches minimum of clear width, measured between the handrails, so the built structure has to be wider than that.
How big does a ramp landing have to be? 60 inches long minimum, and at least as wide as the ramp run leading into it. Where the ramp changes direction, the landing must be 60 by 60 inches minimum.
Does a ramp need a landing at the bottom? Yes. The ADA standard requires landings at both the top and the bottom of each run, and the landing must be essentially level rather than continuing a driveway slope.
How level does a landing have to be? The ADA standard permits a slope no steeper than 1:48 in any direction on a landing, and does not allow changes in level within it.
What is edge protection on a ramp? A curb, barrier, or extended surface that stops a wheel leaving the side. The ADA standard requires it along ramp runs and landings, and a curb option must block a 4 inch sphere near the surface.
Can a door open onto a ramp landing? Only if the landing is large enough that the door swing does not push someone off it. The ADA standard permits door maneuvering clearances to overlap the landing area, but the swing still has to be planned for.
How much yard does a ramp actually need? Ramp length plus both landings. A 24 inch rise at 1:12 is 24 feet of ramp plus roughly 10 feet of landings in a straight line, which is why switchback layouts are so common.
The Bottom Line
Width and landings decide whether a ramp works in practice: 36 inches clear between the handrails, 60 inch landings at each end, 60 by 60 inches at every turn, level surfaces, and edge protection along the whole thing. Add the landings to the ramp length before deciding the yard is big enough, and sort out the door swing at the top first. Start with the length calculation, then check the geometry against the full ramp requirements.
